JFQD – Double Sided Box Type Met Polypropylene Film Capacitor Features
- Double sided metallized polypropylene structure
- Low loss and small inherent temperature rise
- Excellent active and passive flame resistant abilities.
- Negative temperature coefficient of capacitance
| Reference Standard | GB/T14579 (IEC 60384-17) | ||
|---|---|---|---|
| Operating Temperature Range | -40°C~ +85°C | ||
| Rated Voltage | 630V, 1600V, 2000V.DC | ||
| Capacitance Range | 0.001 ~ 0.068μF | ||
| Capacitance Tolerance | ±5%(J), ±10%(K) | ||
| Voltage Proof | 1.75UR (5s), Charge current ≤50mA | ||
| Dissipation Factor | ≤0.0010 (1KHz, 20°C) | ||
| Insulation Resistance | C≤0.33, IR≥50000MΩ C>0.33µF, IR≥15000S (MΩ/µF) |
(20°C, 100V, 1min) | |
