Description
JCB – 2000H at 105°C, Bi-polar SMD Aluminum Electrolytic Capacitor Features
- Bi-polar with general temperature -55℃ to +105℃.
- Load life of 2000 hours.
Operating Temperature | -55°C~ +105°C | |
---|---|---|
Voltage Range | 6.3V ~ 50V.DC | |
Capacitance Range | 0.1 ~ 47μF | |
Capacitance Tolerance | ±20% at 120Hz, 20°C | |
Leakage Current | Leakage current≤ 0.05CV or 10μA, whichever is greater (after 2 minutes application of rated voltage) |
